This paper presents the instrumentation planned and implemented during construction and evaluation and study of the behavior of the dam and the underground structures post construction with respect to performance and safety monitored by various instruments. Based on the analysis of the instrumentation data the 92m high concrete gravity dam is found to be working satisfactorily. The underground Power House cavern is still undergoing stabilization probably in view of it being situated near the main dislocation features of Main Central Thrust MCT and Main Boundary Thrust MBT of western Bhutan which is indicated by instrumentation data and manifested by some rock bolt failures from the walls of the cavern.

California Hospitals Seismic Safety Laws: Instrumentation Of The New San Francisco General Hospital

The cavern is being closely monitored by analysis of data collected from existing geotechnical instruments. The project involved construction of a 92m high concrete gravity dam with peaking live storage capacity of 3. The project taken up for execution from the zero level of infrastructure development on 1st October and the first unit was commissioned on 31st July, and started generating revenue to the Government exchequer. The bed rock was found below 17m thick overburden and weathered rock mass during construction.

The purpose of dam instrumentation and monitoring in general is to maintain and improve safety by providing information to evaluate whether the structure is performing as expected and warn of any changes that could endanger the safety of dam. It has seven concrete blocks with five sluice spillway, one overflow and non-overflow blocks. The sluice spillway is designed to pass standard project flood of cumecs and PMF of about 10,cumecs. Most of the instruments are embedded in blocks 2 and 5 which represents non-overflow and maximum over-flow sections of the dam respectively.

Multi point borehole extensometers have been installed at right and left abutments. Four numbers of strong motion accelerometers have been installed at different locations. The details of instruments being monitored during operation stage is shown in Table 1 below.

Table: 1 Sl. Table: 2 Sl. Average values Name of Instrument Parameter No.
